유량을 조절하는 Inlet Guide Vane은 0~100%혹은 Min ~ Max이나고객요청에 의해서 Indicating을 추가로 변경하였습니다. 0~100%까지

조립중

2024 Recycle Nitrogen Compressor This is the assembly process and we are waiting for the main motor. RIO panel by customer This is from customer and we have to check all the terminal block inside according to the drawing and it needs to be updated. To be ready for test conditions, the after cooler will not be used for the internal test to mert the inlet temperature of the compressor. Also, the d..

MAC Main Air Compressor This is large capacity centrifugal compressor. Flow rate: The normal flow rate is 148,000 Nm3/hr and the design flow rate is 154,000Nm3/hr. Pressure: Inlet pressure is 0.1MpaA and discharge pressure is 0.63MpaA. Temperature: Inlet temperature is 308.15K and discharge temperature is 313.15K. Internal test: The height between ground to motor is about 8.6m. Inter cooler with..

https://www.voidtools.com/ko-kr/ voidtools Everything 실시간 파일/폴더 검색 작은 설치파일 깔끔하고 단순한 UI 빠른 파일 색인 빠른 검색 최저 자원 사용 쉬운 파일 공유 실시간 갱신 등등... Everything 1.4.1.1009 다운로드 32비트 설치파일 64비 www.voidtools.com

SAES-B-054 스펙입니다. 온쇼어, 오프쇼어 플랜트 시설에서 정비, 오퍼레이션을 위해서 이에 따른 접근, 출입구, 장비 조작등을 하기 위한 최소한의 가이드라인입니다. 유지보수를 위해서 적어도 이 스펙만큼은 지켜라 뭐 이런 거 같아요. Scope: Access, egress, and materials handling requirements for maintenance and operation of onshore and offshore plant facilities. 1. Scope 2. Conflicts and Deviations 3. References 4. Definitions 5. Access and Egress Requirements 6. Materials Handling for Operati..

9 Vendor Data 9.2 Proposals 9.2.3 Technical Data Add to list s. A list of priced capital spares 9.3 Contract Data 9.3.4 Parts Lists and Recommended Spares Add to section The vendor shall submit separate lists for following three categories of spares: a. Capital spares b. Commissioning spares c. Operation and maintenance spares. 9.3.4.2 Replace first sentence with The vendor shall provide recomme..

8 Inspection, Testing and Preparation for Shipment 8.2 Inspection 8.2.1 General Add to item c. Final assembly maintenance and running clearances for bearings and seals shall be submitted with as built data. 8.2.2 Material Inspection Add to section Material certificates shall be provided in accordance with Annex B of S-612Q. 8.3 Testing 8.3.2 Hydrostatic Tests 8.3.2.1 Add after first sentenc e Mi..

7 Accessories 7.1 Drivers 7.1.1 General 7.1.1.5 Replace section with The driver nameplate rating, exclusive of the service factor, shall be at least 110 % of the maximum power required for all of the specified operating conditions. 7.1.2 Electric Motors Replace section with 7.1.2.1 Add new section 7.1.2.1.1 Motors shall conform to either IEC 60034, NEMA MG-1 or IEEE 841, unless otherwise specifi..

Supplementary Specification to API Standard 672 Packaged, Integrally Geared Centrifugal Air Compressors 요약 - API 672 4th에 적용 (현재는 API 5th 이 나와있음) - Shaft power 1500kW에 해당되는 공기 압축기에 적용 - 6.1.9 The thermodynamic performance test may be performed on one machine of multiple order of identical machines. Acknowledgements This IOGP Specification was prepared by a Joint Industry Project 33 Standardizati..
